Telescopic Hydraulic Cylinder Applications and Advantages, Increasing Your Reach With A Custom Telescopic Cylinder, The Importance Of The Design Phase In A Custom Telescopic Cylinder. Telescopic hydraulic cylinders utilize multiple nested stages, achieving a long working stroke in compact/retracted form. At the most simplified level, all cylinders generate force and motion in the same way. The mast is erected to the vertical position using a telescopic cylinder. The collapsed package size plus long stroke capability of a telescopic cylinder is one of the advantages the design offers over a rod cylinder. Contrary to this, if the available surface area is small, a higher pressure will be required to move the load. In a typical dump application, the truck or trailer body will be lifted into the air by the cylinder and the weight of the body will cause the cylinder to retract. This special combination is much less complex and much less costly than using an entirely double acting design. In this case, the stages are decreasing and the load is decreasing throughout the stroke of the cylinder (See the blue line in Figure 1 as an example). They both feature a telescopic design consisting of several at most six, stages, each fitting compactly into the other. pressure intensifying effect can occur causing seal failure or even causing the metal sleeve to balloon outward. For example, the weight of a dump body plus the material in it creates a load that requires a specific force to be applied in order to move or dump the material. Experience across various markets and hydraulic applications helps us understand your unique challenges and design the best solution for the equipment and operating environment. This external weight must obviously be sufficient to overcome the friction and mechanical losses within the machine design even after the work portion of the machine cycle has been accomplished. Too much pressure will cause the nested sleeves to balloon outward, bind the mechanism and stop moving. Several things can limit the force applied by a cylinder. Choosing the right telescopic cylinder design also requires knowledge of the number of stages, stroke length, and largest OD stage (outside diameter). The smaller inner sleeves are called the stages. For example, if the system pressure is limited to 2000 PSI and the largest diameter available in the telescopic cylinder is 7", the cylinder will only be able to produce a maximum force of 38.5 tons. This shaver technology offers unmatched performance in certain applications. Partially double-acting cylinders are typically used in over-center applications. During typical operation of a dump truck the initial pressure to start raising the truck body or trailer should never exceed 600800 PSI.
They are ideal for dump truck or platform truck trailer equipment. If the weight or force pushing on the cylinder is large it will cause the cylinder to collapse quickly. There are exceptions however, with one pneumatic cylinder manufacturer successfully incorporating up to 9 stages in their cylinder designs. A fluid is forced into the vessel and it pushes against a movable surface. The remaining stages, therefore, are single acting. sales@hydrauliccylindersinc.com. Often such hydraulic systems are equipped with shock suppressing components, such as hydraulic accumulators, to absorb pressure spikes. In some cases the body of the truck or trailer may go "over center," meaning that the body of the vehicle is now pulling on the cylinder once fully extended.
Heavy duty telescopic cylinders are usually powered by oil hydraulics, whereas some lighter duty units could also be powered by compressed air. The changing diameters from the cylinder extending and retracting result in a change in the required pressure, as the various stages are moving. When the piston face catches up again and strikes the oil column a pressure spike occurs which can damage the actuator.[4]. More complex than single-acting cylinders, double-acting telescopic cylinders retract and extend via hydraulic pressure. Phelps packing is compatible with standard hydraulic oils. Generally a telescopic cylinder will be used in applications where a constant force is not required. With the ability to extend further, it is the ideal hydraulic cylinder for such heavy-duty equipment as dump trucks, excavators, and garbage trucks. While a rod cylinder could potentially perform the job it may be too long when fully collapsed, where as a telescopic cylinder will typically be significantly shorter when in the same position. Top and bottom on pin mount models. Plunger rod can be double acting and sleeves single-acting. Telescopic cylinders are designed with a series of steel or aluminum[2] tubes of progressively smaller diameters nested within each other. Correctly sizing the cylinder for the application is key based on the maximum force needed and the available maximum system pressure. 2721, 341 North Road This technique is necessary when very long strokes are required compared to the installation length of the cylinder. Copyright 2019 Phelps Industries, Inc. Privacy Policy | Terms and ConditionsAll Rights Reserved. [4], Hydraulic telescopic cylinders are often limited to a maximum hydraulic pressure of 2000-3000 psi. Knowing you need a telescopic cylinder versus a welded rod or tie-rod cylinder is the first step. At this high flow rate, there will be a lot of back pressure that can damage the cylinder or the system. As the double acting cylinder extends, it forces oil out of the retract port. This can, in some applications, prove to be very difficult to connect with hydraulic hoses due to the distance between these ports at full extension. While all are considered telescopic cylinders, each cylinder type has its own advantages. Anexperienced engineering teamhelps you work through design considerations to ensure your cylinder meets your requirements. They are often iron rings or glass reinforced nylon seals. Thus a double acting telescopic actuator usually retracts starting from the smallest diameter stage to finish with the largest stage retracting lastly. These are single and double-acting.
As oil is supplied to the cylinder, pressure builds in an attempt to move the stages. [1] Some pneumatic telescoping units are manufactured with retracted lengths of under 15% of overall extended unit length. Aggressive Hydraulicsdesigns and engineers application-specific telescopic cylinders, purpose-built to withstand demanding applications and work environments. Please enable cookies on your browser and try again. How Do I Know Its Time to Repair My Hydraulic Cylinders? The sealing system used is stacked V-packing rings or single lip U-cups molded specifically for Phelps Telescopic Cylinders.
An example of this is erecting the mast of a large mobile drilling rig. Controls can be arranged to extend a single telescopic cylinder or to operate a series of telescopic cylinders. Packing is accessible under external gland nuts, removable with supplied spanner wrench, allowing ease of packing adjustment or replacement. To accomplish this long travel with a conventional hydraulic cylinder is very difficult considering that the collapsed length of a single stage rod cylinder is approximately 110% of its output stroke. Once the tilt back has been initiated, then gravity takes over and supplies the force to complete the full cylinder retraction. You will be redirected once the validation is complete. We offer a full line of four stage, single acting telescopic cylinders with five standard series of sizes. For instance, if there is a large over-hung load past the dump hinge a lower force is required to extend the cylinder. Refuse pack or eject vehicles and various ejector trailers are typical applications for the double acting cylinder. www.powermotiontech.com is using a security service for protection against online attacks. Common cylinder functions include platform lifts, dump hoists, dump lifts, and pack/eject, Base end mount configurations include drilled thru lug, cross-tube, spherical bearing, and trunnion, Typical rod end mount positioning includes drilled thru lug, drilled thru rod, spherical bearing, trunnion, and ball mount configurations. As the dump angle increases during the extension of the cylinder, less weight is applied to the cylinder while more weight shifts to the rear hinge (See the red line in Figure 1 for this situation). Each one may present unique challenges beyond those that apply to the applications covered; however, the general concept remains the same. In the case of a dump truck/trailer the distance between where the cylinder is mounted and where the dump hinge is located can affect performance. Each design offers specific advantages; both types are suitable for fitting into tight spaces. Thus if the hydraulic fluid return line is blocked during extension a Our quality control program is continuous throughout the production of each telescopic cylinder. This field is for validation purposes and should be left unchanged. It performs optimally where a rod-cylinder cannot. Engineers in almost all of the worlds industries require hydraulic cylinders capable of providing sufficient force to move huge loads. Phone: 763-452-0540 Applications that are horizontal, or near horizontal, will have pressure signatures similar in nature to those noted in Figure 1. Larger telescopic stage sizes include: 15.125, 13.25, 11.5, 10, 8.5 and 7 nominal. We can help you discover whether this option can prove to be advantageous for your company and its machinery. Our telescopic hydraulic cylinders are performance-built, made in the USA, and ready to work for you. [2], Telescopic cylinders require careful design as they are subjected to large side forces especially at full extension.
Thus, the plunger stage only of the telescopic actuator is equipped as a double acting cylinder to provide the initial force to pull the mast back from vertical. Double acting telescopic cylinders are thus much more complex in design than the single acting type. At Southern Hydraulic Cylinder, our engineers and technicians will work with you to ensure you understand your options, including what type of telescopic cylinders will prove to be the most effective and efficient. A number of other special designs also exist including a hybrid single/double acting design, and a constant speed, constant thrust design. The pressure must also build to a high enough level within a double acting cylinder to allow it to retract; however, the pressures required to retract a telescopic cylinder can be much higher than the pressures required to extendthat is if the same forces are required to extend and retract. 2010-2022 Mailhot | Allrightsreserved, Mailhot | Manufacturer of hydraulic cylinders at the forefront of technology since 1956 |, 2010-2022 Mailhot | Allrightsreserved, Protects cylinder from scratching or other potential surface damage, Variable warranty offered depending on the product and its use, Improved corrosion and wear resistance with NCERA, Operating pressures up to 3000 psi (207 bar).
They are ideal for dump truck or platform truck trailer equipment. If the weight or force pushing on the cylinder is large it will cause the cylinder to collapse quickly. There are exceptions however, with one pneumatic cylinder manufacturer successfully incorporating up to 9 stages in their cylinder designs. A fluid is forced into the vessel and it pushes against a movable surface. The remaining stages, therefore, are single acting. sales@hydrauliccylindersinc.com. Often such hydraulic systems are equipped with shock suppressing components, such as hydraulic accumulators, to absorb pressure spikes. In some cases the body of the truck or trailer may go "over center," meaning that the body of the vehicle is now pulling on the cylinder once fully extended.
Heavy duty telescopic cylinders are usually powered by oil hydraulics, whereas some lighter duty units could also be powered by compressed air. The changing diameters from the cylinder extending and retracting result in a change in the required pressure, as the various stages are moving. When the piston face catches up again and strikes the oil column a pressure spike occurs which can damage the actuator.[4]. More complex than single-acting cylinders, double-acting telescopic cylinders retract and extend via hydraulic pressure. Phelps packing is compatible with standard hydraulic oils. Generally a telescopic cylinder will be used in applications where a constant force is not required. With the ability to extend further, it is the ideal hydraulic cylinder for such heavy-duty equipment as dump trucks, excavators, and garbage trucks. While a rod cylinder could potentially perform the job it may be too long when fully collapsed, where as a telescopic cylinder will typically be significantly shorter when in the same position. Top and bottom on pin mount models. Plunger rod can be double acting and sleeves single-acting. Telescopic cylinders are designed with a series of steel or aluminum[2] tubes of progressively smaller diameters nested within each other. Correctly sizing the cylinder for the application is key based on the maximum force needed and the available maximum system pressure. 2721, 341 North Road This technique is necessary when very long strokes are required compared to the installation length of the cylinder. Copyright 2019 Phelps Industries, Inc. Privacy Policy | Terms and ConditionsAll Rights Reserved. [4], Hydraulic telescopic cylinders are often limited to a maximum hydraulic pressure of 2000-3000 psi. Knowing you need a telescopic cylinder versus a welded rod or tie-rod cylinder is the first step. At this high flow rate, there will be a lot of back pressure that can damage the cylinder or the system. As the double acting cylinder extends, it forces oil out of the retract port. This can, in some applications, prove to be very difficult to connect with hydraulic hoses due to the distance between these ports at full extension. While all are considered telescopic cylinders, each cylinder type has its own advantages. Anexperienced engineering teamhelps you work through design considerations to ensure your cylinder meets your requirements. They are often iron rings or glass reinforced nylon seals. Thus a double acting telescopic actuator usually retracts starting from the smallest diameter stage to finish with the largest stage retracting lastly. These are single and double-acting. As oil is supplied to the cylinder, pressure builds in an attempt to move the stages. [1] Some pneumatic telescoping units are manufactured with retracted lengths of under 15% of overall extended unit length. Aggressive Hydraulicsdesigns and engineers application-specific telescopic cylinders, purpose-built to withstand demanding applications and work environments. Please enable cookies on your browser and try again. How Do I Know Its Time to Repair My Hydraulic Cylinders? The sealing system used is stacked V-packing rings or single lip U-cups molded specifically for Phelps Telescopic Cylinders.
An example of this is erecting the mast of a large mobile drilling rig. Controls can be arranged to extend a single telescopic cylinder or to operate a series of telescopic cylinders. Packing is accessible under external gland nuts, removable with supplied spanner wrench, allowing ease of packing adjustment or replacement. To accomplish this long travel with a conventional hydraulic cylinder is very difficult considering that the collapsed length of a single stage rod cylinder is approximately 110% of its output stroke. Once the tilt back has been initiated, then gravity takes over and supplies the force to complete the full cylinder retraction. You will be redirected once the validation is complete. We offer a full line of four stage, single acting telescopic cylinders with five standard series of sizes. For instance, if there is a large over-hung load past the dump hinge a lower force is required to extend the cylinder. Refuse pack or eject vehicles and various ejector trailers are typical applications for the double acting cylinder. www.powermotiontech.com is using a security service for protection against online attacks. Common cylinder functions include platform lifts, dump hoists, dump lifts, and pack/eject, Base end mount configurations include drilled thru lug, cross-tube, spherical bearing, and trunnion, Typical rod end mount positioning includes drilled thru lug, drilled thru rod, spherical bearing, trunnion, and ball mount configurations. As the dump angle increases during the extension of the cylinder, less weight is applied to the cylinder while more weight shifts to the rear hinge (See the red line in Figure 1 for this situation). Each one may present unique challenges beyond those that apply to the applications covered; however, the general concept remains the same. In the case of a dump truck/trailer the distance between where the cylinder is mounted and where the dump hinge is located can affect performance. Each design offers specific advantages; both types are suitable for fitting into tight spaces. Thus if the hydraulic fluid return line is blocked during extension a Our quality control program is continuous throughout the production of each telescopic cylinder. This field is for validation purposes and should be left unchanged. It performs optimally where a rod-cylinder cannot. Engineers in almost all of the worlds industries require hydraulic cylinders capable of providing sufficient force to move huge loads. Phone: 763-452-0540 Applications that are horizontal, or near horizontal, will have pressure signatures similar in nature to those noted in Figure 1. Larger telescopic stage sizes include: 15.125, 13.25, 11.5, 10, 8.5 and 7 nominal. We can help you discover whether this option can prove to be advantageous for your company and its machinery. Our telescopic hydraulic cylinders are performance-built, made in the USA, and ready to work for you. [2], Telescopic cylinders require careful design as they are subjected to large side forces especially at full extension.
Thus, the plunger stage only of the telescopic actuator is equipped as a double acting cylinder to provide the initial force to pull the mast back from vertical. Double acting telescopic cylinders are thus much more complex in design than the single acting type. At Southern Hydraulic Cylinder, our engineers and technicians will work with you to ensure you understand your options, including what type of telescopic cylinders will prove to be the most effective and efficient. A number of other special designs also exist including a hybrid single/double acting design, and a constant speed, constant thrust design. The pressure must also build to a high enough level within a double acting cylinder to allow it to retract; however, the pressures required to retract a telescopic cylinder can be much higher than the pressures required to extendthat is if the same forces are required to extend and retract. 2010-2022 Mailhot | Allrightsreserved, Mailhot | Manufacturer of hydraulic cylinders at the forefront of technology since 1956 |, 2010-2022 Mailhot | Allrightsreserved, Protects cylinder from scratching or other potential surface damage, Variable warranty offered depending on the product and its use, Improved corrosion and wear resistance with NCERA, Operating pressures up to 3000 psi (207 bar).
